TCMX Mixed Type
A Mixed type series to increase production efficiency and open the way to versatile embroidery expressions!
Chenille embroidery and standard embroidery have been brought together in one embroidery machine.
A chenille embroidery head is coupled with a standard embroidery head in a pair (available up to 15 pairs).
TCMX 600 Type
Multi-head embroidery machines, specialized for chenille embroidery, in the pursuit of high speed, quietness and productivity.
Stable stitching is available at the industry’s fastest speed of 750rpm in lineup up to 23 heads!
TCMX-Mixed Type Series
| Model | Needles | Pairs | Chenille heads | Multicolor heads | Head interval | Embroidery space | Table size D×Wmm |
|
|---|---|---|---|---|---|---|---|---|
| D×W（offset） | Continuous(W) | |||||||
| TCMX-60912 | 6/9 | 12 | 12 | 12 | 510 | 680×510（230） | 6.120 | 1.830×8.115 |
| TCMX-60912 | 6/9 | 12 | 12 | 12 | 510 | 1.200×510（230） | 6.120 | 2.870×8.115 |
| TCMX-60915 | 6/9 | 15 | 15 | 15 | 480 | 680×480（230） | 7.200 | 1.830×9.165 |
| TCMX-60915 | 6/9 | 15 | 15 | 15 | 480 | 800×480（230） | 7.200 | 2.070×9.165 |
| TCMX-60915 | 6/9 | 15 | 15 | 15 | 480 | 1.000×480（230） | 7.200 | 2.470×9.165 |
| TCMX-60915 | 6/9 | 15 | 15 | 15 | 480 | 1.200×480（230） | 7.200 | 2.870×9.165 |
| TCMX-60915 | 6/9 | 15 | 15 | 15 | 480 | 1.500×480（230） | 7.200 | 3.470×9.165 |
| TCMX-61201 | 6/12 | 1 | 1 | 1 | 600 | 680×600（275） | 600 | 1.820×2.615 |
| TCMX-61202 | 6/12 | 2 | 2 | 2 | 600 | 680×600（275） | 1.200 | 1.820×3.215 |
| TCMX-61202 | 6/12 | 2 | 2 | 2 | 600 | 1.200×600（275） | 1.200 | 2.860×3.215 |
